| 详细参数 | |||
|---|---|---|---|
| 品牌 | 奥林巴斯 | 型号 | LCPLFLN50XLCD |
| 类型 | 正置式金相显微 | 仪器最大放大倍数 | 500 |
| 目镜放大倍数 | 10 | 物镜放大倍数 | 50X |
| 用途 | 其他 | 装箱数 | 1 |
| 加工定制 | 否 | 外形尺寸 | 其他 |
| 重量 | 0.55KG | 产地 | 其他 |
长工作距离平场半复消色差物镜 LCPLFLN50X LCD
长工作距离平场半复消色差物镜 LCPLFLN50X LCD
长工作距离平场半复消色差透镜 LCPLFLN20X/50XLCD
| Magnification [X] | 50 |
|---|---|
| Numerical aperture (NA) | 0.7 |
| Working distance (WD) [mm] | 2.20 - 3.00 |
| Objective Field Number | 26.5 |
| Immersion medium | Air/Dry |
| Spring loaded | N/A |
| Correction collar | Yes |
| Correction range of correction collar | Glass: 0 - 1.2mm |
| Iris | N/A |
| Correction level of chromatic aberration |
Semi-apochromat |
| Parfocalizing distance [mm] | 45 |
| Back focal plane (BFP) b | -3.0 |
| Type of screw thread | W20.32X0.706(RMS) |
| Brightfield(Reflected) | Good |
| Brightfield(Transmitted) | Good |
| Darkfield(Reflected) | N/A |
| Darkfield(Transmitted) | N/A |
| DIC(Reflected) | Limitation |
| DIC(Transmitted) | N/A |
| Phase Contrast | N/A |
| Relief Contrast | N/A |
| Polarized Light | N/A |
| Fluorescence (B, G Excitation) | N/A |
| UV Fluorescence (at 365nm) | N/A |
| Multiphoton | N/A |
| TIRF | N/A |
| IR | N/A |
| WLI | N/A |
| Auto Focus | N/A |
